SC-AFFF Plus Extinguisher


  • Mounting :
 Surface / cabinet
  • Cylinder :
 High grade molded steel(SPCEN)
(RoHs / EN71 Standard)
  • Cylinder inner :
 Coating prevent corrosion with
PPA665XL (Technology from UK)
  • Paint :
 Free from heavy metals
(JIS Standard)

  • Handle :
 Standless

Description


  • * Proper to extinguish fire type A, B, C and K
  • * Can be use as subsidy of halon extinguisher
  • * No smoke and able to see through during shooting.
  • * Proper to store in hygene place such as office,  shop, apartment, home, kichen, hospitald, labotary and etc.

Specifications

Sizes: 2.2 Lbs. 5 Lbs. 10 Lbs. 15 Lbs. 50 Lbs.
Weight of agent: 1.0 Kg 2.3 Kg 4.5 Kg 6.8 Kg 23.0 Kg
Weight of container: 0.8 kg 1.5 Kg 2.3 Kg 2.7 Kg 18.8 Kg
Gross weight: 1.8 Kg 3.8 Kg 6.8 Kg 9.5 Kg 42.1 kg
Overall height: 299 mm  385 mm 510 mm 555 mm 970 mm
Diameter: 90 mm 114.5 mm 137.5 mm 151.5 mm 200.5 mm
Propellant: Nitrogen
Working pressure at 27 ± 2 °C: 1.21 MPa
175 PSI		 1.34 MPa
195 PSI
Fire rating (Tested and approved by TISTR) N/A 10A20B 10A40B N/A
Aprox discharging time: 10 Sec. 15 Sec. 20 Sec. 35 Sec.
Shooting range: 2-3 m. 4-6 m. 6-8 m.

Cautions


  • * Must be refilled by qualified by company
  • * Refill with SC-AFFF Plus agent only
  • * Do not store at high temperatures above 49°C(120°F)
  • * Keep away from children


Maintenance


  • * Check the pressure guage and inspect extinguisher monthly.
  • * Examine that the hose is unobstructed.
  • * Guage pointer must be in green area, if pointer is not in green area or the weight is below gross weight, please contact us immediately.

Warranty


  • * 2 years warranty
  • * Terms and conditions as designated by the company.
