Dry Chemical Extinguisher_Official Website | Fire Kings Equipment Co.,Ltd.

Description

Specifications

Sizes:	2.2 Lbs.	5 Lbs.	10 Lbs.	15 Lbs.	20 Lbs.	50 Lbs.
Weight of agent:	1.0 Kg	2.3 Kg	4.6 Kg	6.8 Kg	9.0 Kg	23.0 Kg
Weight of container:	0.8 kg	1.3 Kg	2.2 Kg	2.5 Kg	3.8 Kg	18.8 Kg
Gross weight:	1.8 Kg	3.6 Kg	6.8 Kg	9.3 Kg	12.8 Kg	41.8 kg
Overall height:	300 mm	385 mm	510 mm	555 mm	610 mm	970 mm
Diameter:	90 mm	114.5 mm	137.5 mm	151.5 mm	176 mm	200.5 mm
Propellant:	Nitrogen
Working pressure at 27 ± 2 °C:	1.21 MPa 175 PSI	1.34 MPa 195 PSI
Aprox discharging time:	10 Sec.		15 Sec.	20 Sec.	25 Sec.	35 Sec.
Shooting range:	2-3 m.	4-6 m.	6-8 m.

* Check the pressure guage and inspect extinguisher monthly.
* Examine that the hose is unobstructed.
* Guage pointer must be in green area, if pointer is not in green area or the weight is below gross weight, please contact us immediately.
