AFFF Extinguisher


  • Mounting :
 Surface / cabinet
  • Cylinder :
 Stainless
  • Paint :
 Free from heavy metals
( JIS Standard )

  • Handle :
 Standless

Description


  • * Proper to extinguish fire type A and B
  • * Able to store in common place such as storage room, factory and etc.

Specifications

Sizes: 2.3 Litre 6 Litre 9 Litre
Weight of agent: 2.3 Litre 6 Litre 9 Litre
Weight of container: 1.3 kg 3.1 Kg 3.7 Kg
Gross weight: 3.6 Kg 10.4 Kg 13.1 Kg
Overall height: 400 mm  520 mm 630 mm
Diameter: 119 mm 180 mm
Propellant: Nitrogen
Working pressure at 27 ± 2 °C: 1.34 MPa
195 PSI
Aprox discharging time: 10 Sec. 15 Sec. 25 Sec.
Shooting range: 4-6 m. 6-8 m.

Cautions


  • * Can't be use to extinguisher fire that caused from electricity( C )
  • * Must be refilled by qualified by company
  • * Refill with AFFF agent only
  • * Do not store at high temperatures above 49°C(120°F)
  • * Keep away from children


Maintenance


  • * Check the pressure guage and inspect extinguisher monthly.
  • * Examine that the hose is unobstructed.
  • * Guage pointer must be in green area, if pointer is not in green area or the weight is below gross weight, please contact us immediately.

Warranty


  • * 2 year warranty
  • * Terms and conditions as designated by the company.
