BF2000 Extinguisher


  • Mounting :
Surface / cabinet
  • Cylinder :
High grade molded steel(SPCEN)
( RoHs / EN71 Standard )
  • Paint :
Free from heavy metals
( JIS Standard )


  • Handle :
Standless

Description


  • * Proper to extinguish fire type A,B and C
  • * Proper to store in hygene place such as hospital,  server room and etc.

Specifications

Sizes: 2.2 Lbs. 5 Lbs. 10 Lbs. 15 Lbs. 50 Lbs.
Weight of agent: 1.0 Kg 2.3 Kg 4.5 Kg 6.8 Kg 23.0 Kg
Weight of container: 0.8 kg 1.3 Kg 2.2 Kg 2.5 Kg 18.8 Kg
Gross weight: 1.8 Kg 3.6 Kg 6.7 Kg 9.3 Kg 41.8 kg
Overall height: 299 mm  385 mm 510 mm 555 mm 970 mm
Diameter: 90 mm 114.5 mm 137.5 mm 151.5 mm 200.5 mm
Propellant: Nitrogen
Working pressure at 27 ± 2 °C: 1.21 MPa
175 PSI
1.34 MPa
195 PSI
Aprox discharging time: 10 Sec. 15 Sec. 20 Sec. 35 Sec.
Shooting range: 2-3 m. 4-6 m. 6-8 m.

Cautions


  • * Must be refilled by qualified by company
  • * Refill with BF-2000 agent only
  • * Do not store at high temperatures above 49°C(120°F)
  • * Keep away from children


Maintenance


  • * Check the pressure guage and inspect extinguisher monthly.
  • * Examine that the hose is unobstructed.
  • * Guage pointer must be in green area, if pointer is not in green area or the weight is below gross weight, please contact us immediately.

Warranty


  • * 1 year warranty
  • * Terms and conditions as designated by the company.
